Trailer Coupling for 2003 Mercedes-Benz E55 AMG
No.
Part # / Description / Price
Price
15
Cover Cap
Mercedes-Benz
Mercedes-Benz Description: Trailer hitch. Trailer coupling. Ball head to a 220 310 01 95.
MSRP $13.50
$11.18
MSRP $13.50
$11.18
20
Gasket Mercedes-Benz
Mercedes-Benz Description: At cross member. Cross member for trailer coupling to rear cross member. Left and right.
30
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: Crossbeam to rear longitudinal memb.. M12X35
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Cross member to side members. Reinforcement to cross member. Caliper to steering knuckle.
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Cross member to side members. Reinforcement to cross member. Caliper to steering knuckle.
MSRP $6.50
$5.38
MSRP $6.50
$5.38
220
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: Mounting to basic carrier. M6X55
Diameter: 6mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm. Valve to carrier. Operating lever on console. Front rubber mounting.
Diameter: 6mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm. Valve to carrier. Operating lever on console. Front rubber mounting.
MSRP $9.00
$7.45
MSRP $9.00
$7.45
230
260
Bolt And Washer Assembly Mercedes-Benz
Mercedes-Benz Description: Reinforcement to side member. M10X25
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1mm. Reinforcement to body longitudinal member. Strut to reinforcement. Intermediate bearing to frame floor unit. Reinforcement to longitudinal member, left.
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1mm. Reinforcement to body longitudinal member. Strut to reinforcement. Intermediate bearing to frame floor unit. Reinforcement to longitudinal member, left.
MSRP $3.50
$2.90
MSRP $3.50
$2.90
500
Exchange Control Unit 1 Mercedes-Benz
Mercedes-Benz Notes: PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
Description: Trailer coupling.
520
Expansion Rivet Mercedes-Benz
Mercedes-Benz Description: Folding aid on cover. Covering to shell-type handle. Lining under loading floor to right side member. Frame to lock elegance.
MSRP $3.20
$2.62
MSRP $3.20
$2.62
600
610
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: Rear rpm sensor connector x62/1. MQS. 0.5 MM2 MQS SN
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
MSRP $9.50
$7.87
MSRP $9.50
$7.87
720
MSRP $10.00
$8.14
1 This price excludes a refundable manufacturer's core charge. Add the part to your cart to see the core charge.
