Cable Harness for Roof for 2005 Mercedes-Benz C 230
No.
Part # / Description / Price
Price
42
Receptacle Housing
Mercedes-Benz
Mercedes-Benz Description: Contact strip front pass. Side yel. Automatic child seat recognition. 4-pin mqs
model 1: mqs
slots: 4. Seat contacting. 4-pin mqs
model 1: mqs
slots: 4. Separation point, upfront sensor, driver x18/38. 4-pin mqs
model 1: mqs
slots: 4.
model 1: mqs
slots: 4. Seat contacting. 4-pin mqs
model 1: mqs
slots: 4. Separation point, upfront sensor, driver x18/38. 4-pin mqs
model 1: mqs
slots: 4.
MSRP $4.50
$3.73
MSRP $4.50
$3.73
52
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Cockpit switch train s6/1. 6 pin mqs. Pneumatic control unit. 6 pin mqs. Steering column adjustment motor. 6 pin mqs. Mod. Black n72/1. 6 pin mqs. Bus node roof. 6 pin mqs. Roof mounted operating unit. 6 pin mqs. Folding top actuation switch s84/10. 6 pin mqs. Connector, overhead control panel, ffsblack x25/8. 6 pin mqs. Upper control panel n72/1. 6 pin mqs.
MSRP $8.50
$6.90
MSRP $8.50
$6.90
65
Plug Mercedes-Benz
Mercedes-Benz Description: Intermediate connector, speaker x38*1-s, x38*2-s, x38*3-s. 4-pin mqs. Connector emergency call pushbutton x18/37. 4-pin mqs. Interior/roof connector x42/28. 4-pin mqs. Tv/tuner antenna connector x1/28. 4-pin mqs. Intermediate connector, left speaker x38. 4-pin mqs. E-call pushbutton. 4-pin mqs. Volume control x60. 4-pin mqs. Separation point. 4-pin mqs. Burglary alarm system plug-connection x42/28. 4-pin mqs.
70
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: Rear rpm sensor connector x62/1. MQS. 0.5 MM2 MQS SN
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
MSRP $9.50
$7.87
MSRP $9.50
$7.87
100
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Emergency call microphone. Emergency switch.
120
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: To a 000 545 95 03. To a 001 545 51 40. T0 a 001 545 52 40. To a 001 545 520 40. To a 001 545 28 81. To 001 545 52 40.
MSRP $7.75
$6.35
MSRP $7.75
$6.35
120
Plug Mercedes-Benz
Mercedes-Benz Description: Central antenna separation point (tpm) x1/50. 6-pinmodel 1: mqsslots: 6. Rear axle transfer case plugconnection (x62/8). 6-pinmodel 1: mqsslots: 6. Separation point, micro array x39/69 mic out. 6-pinmodel 1: mqsslots: 6. Separation point, micro array x39/6 ...
MSRP $3.90
$3.17
MSRP $3.90
$3.17
135
Crimp Tml Pin Contact Mercedes-Benz
Mercedes-Benz Description: X1/16. 0.5-0.75 MM2 MQSLeitungsquerschnitt Min/Max: 0,5-0,75mm2Oberflächenschutz PINs: SnELA: -Model 1: MQSRelease tool: W220 589 01 99 60Crimp tool: W220 589 01 99 85. Malfunction indicator lamp aut. Breakdown/information button conn. X 39/48. 0.5-0.75 M ...
MSRP $2.80
$2.28
MSRP $2.80
$2.28
