Refrigerant Line Routing for 2017 Mercedes-Benz GLC43 AMG
No.
Part # / Description / Price
Price
10
MSRP $68.00
$53.87
10
Refrigerant Line
Mercedes-Benz
Mercedes-Benz Notes: REPLACEMENT PART CAN ONLY BE ORDERED VIA EDAG SPARE PART PORTAL HTTPS://ETOS.EDAG.DE/.
Description: Compressor to condenser.
20
O-Ring Mercedes-Benz
Mercedes-Benz Description: To evaporator. Line to condenser. Condenser and connecting point 1/2". Condenser to compressor. Pipe line to refrigerant compressor. Piping to refrigerant compressor. Between evaporator and expansion valve.
MSRP $8.75
$7.18
MSRP $8.75
$7.18
25
Mounting Clamp Mercedes-Benz
Mercedes-Benz Description: Fastening, high-pressure line. Line mount.
MSRP $3.40
$2.76
MSRP $3.40
$2.76
40
Hexalobular Screw Mercedes-Benz
Mercedes-Benz Description: Rear lid to hinge lever. Drive to rear pillar. Pipe line to shock absorber leg reinforcement. Strut to front cross member. Bracket to car floor. Cooling pipe to front cross member. Engine hood upper catch to engine hood. Partition panel. Strut to stiffening,front central.
100
Condenser Mercedes-Benz
Mercedes-Benz Description: Compressor to condenser. Refrigerant. Heater/air conditioning. Sprinter van. 2.0l diesel. With heavy duty rear ac. 2.0l diesel.
110
Pressure Sensor Mercedes-Benz
Mercedes-Benz Description: Refrigerant line. Reservoir. Sprinter van. Refrigerant condenser. Refrigerant pressure sensor. Roof. Metris. Rear. At condenser,bottom m10.
MSRP $159.00
$125.40
MSRP $159.00
$125.40
150
Refrigerant Line Mercedes-Benz
Mercedes-Benz Description: Condenser to connecting point. Condenser to refrigerant reservoir.
150
Refrigerant Line Mercedes-Benz
Mercedes-Benz Description: Condenser to separating point. Condenser to refrigerant reservoir. Condenser to connecting point.
MSRP $61.00
$48.55
MSRP $61.00
$48.55
150
Refrigerant Line Mercedes-Benz
Mercedes-Benz Description: Condenser to connecting point. Condenser to refrigerant reservoir.
160
O-Ring Mercedes-Benz
Mercedes-Benz Description: Lower. Condenser and connecting point 3/8". Condenser to connecting point and expansion valve. Pressure line to expansion valve. Refrigerant line to expansion valve and connecting point. Refrigerant line to chiller. Refrigerant line to condenser, expansion valve and refrigerant line . Refrigerant line to shutoff valve. T0 refrigerant line. Refrigerant line to refrigerant line, expansion valve and evaporator.
MSRP $10.50
$8.69
MSRP $10.50
$8.69
190
O-Ring Mercedes-Benz
Mercedes-Benz Description: Intake side. Upper. Expansion valve connection. Line to check valve. Piping to refrigerant compressor. Refrigerant line to connecting point and compressor 3/4". Evaporator. Refrigerant line to expansion valve .
MSRP $5.50
$4.42
MSRP $5.50
$4.42
200
Refrigerant Line Mercedes-Benz
Mercedes-Benz Notes: REPLACEMENT PART CAN ONLY BE ORDERED VIA EDAG SPARE PART PORTAL HTTPS://ETOS.EDAG.DE/.
Description: Connecting point to compressor.
200
MSRP $70.00
$55.20
205
Double End Stud Mercedes-Benz
Mercedes-Benz Description: Refrigerant line to refrigerant line. Connecting point mount. Separation point. Fastening, connecting point. Fastening at expansion valve. Shutoff valve to line. Line to evaporator. Refrigerant lines to condenser.
MSRP $7.50
$6.21
MSRP $7.50
$6.21
300
Refrigerant Line Mercedes-Benz
Mercedes-Benz Description: Connecting point to expansion valve.
MSRP $104.00
$81.84
MSRP $104.00
$81.84
300
Refrigerant Line Mercedes-Benz
Mercedes-Benz Description: Connecting point to expansion valve.
MSRP $135.00
$106.92
MSRP $135.00
$106.92
350
Cutoff Valve Mercedes-Benz
Mercedes-Benz Description: Refrigerant line. Shutoff valve to line.
MSRP $124.00
$97.68
MSRP $124.00
$97.68
380
Feed-Through Grommet Mercedes-Benz
Mercedes-Benz Description: Line to suspension strut. Piping mount. Refrigerant line and holder mount.
MSRP $3.00
$2.48
MSRP $3.00
$2.48
390
Snap Fastener Mercedes-Benz
Mercedes-Benz Description: Pressure sensor. Line to longitudinal member. Piping mount. Left and right inner longitudinal member. Mounting to connecting member. Refrigerant line to suspension strut tower. Line mount. To cover. Right rear longitudinal member, upper. Line to connecting member.
MSRP $2.50
$2.07
MSRP $2.50
$2.07
400
MSRP $1,090.00
$806.00
408
Elastomer Bearing Mercedes-Benz
Mercedes-Benz Description: Bearing. Evaporator to holder . Holder to strut.
MSRP $5.50
$4.55
MSRP $5.50
$4.55
409
Inner Sleeve For Bearing Mercedes-Benz
Mercedes-Benz Description: Elastomer bearing inner sleeve. Evaporator to holder .
418
Temperature Sensor Mercedes-Benz
Mercedes-Benz Description: Temperature sensor, heat exchanger, high-voltage battery. Evaporator .
MSRP $119.00
$93.72
MSRP $119.00
$93.72
419
Hexalobular Screw Mercedes-Benz
Mercedes-Benz Description: Bracket to covering. Filler neck recess m 6x16. Bracket mounting m6x20. Headlamp wiper/washer.
MSRP $3.70
$3.04
MSRP $3.70
$3.04
420
MSRP $42.00
$34.50
425
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: M8x25-8.8. Fuel tank to console. Bracket to mounting plate or to transmission. Bracket to bumper. Shackle to torsion bar. Intermediate bearing to frame.
MSRP $4.20
$3.45
MSRP $4.20
$3.45
427
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: Cross member to left front panel pillar.
MSRP $2.70
$2.21
MSRP $2.70
$2.21
430
MSRP $37.50
$31.05
480
Screw Cap Mercedes-Benz
Mercedes-Benz Description: Filler connection. High-pressure line. Cover, service connection, high pressure, air conditioning system. Filling connection m10x1. High-pressure side M10X1. To refrigerant line. Valve.
MSRP $6.75
$5.52
MSRP $6.75
$5.52
490
Screw Cap Mercedes-Benz
Mercedes-Benz Description: Filler connection. Filling connection. Low-pressure line. Seal. Suction line. Cover, service connection, low pressure, air conditioning system. Low-pressure side M8X1. To refrigerant line. Valve.
MSRP $12.00
$9.94
MSRP $12.00
$9.94
