Refrigerant Line Arrangement for 2017 Mercedes-Benz S550e
No.
Part # / Description / Price
Price
15
O-Ring
Mercedes-Benz
Mercedes-Benz Description: To evaporator. Line to condenser. Condenser and connecting point 1/2". Condenser to compressor. Pipe line to refrigerant compressor. Piping to refrigerant compressor. Between evaporator and expansion valve.
MSRP $8.75
$7.18
MSRP $8.75
$7.18
55
O-Ring Mercedes-Benz
Mercedes-Benz Description: Lower. Condenser and connecting point 3/8". Condenser to connecting point and expansion valve. Pressure line to expansion valve. Refrigerant line to expansion valve and connecting point. Refrigerant line to chiller. Refrigerant line to condenser, expansion valve and refrigerant line . Refrigerant line to shutoff valve. T0 refrigerant line. Refrigerant line to refrigerant line, expansion valve and evaporator.
MSRP $10.50
$8.69
MSRP $10.50
$8.69
65
Feed-Through Grommet Mercedes-Benz
Mercedes-Benz Description: Line to suspension strut. Piping mount. Refrigerant line and holder mount.
MSRP $3.00
$2.48
MSRP $3.00
$2.48
80
Screw Cap Mercedes-Benz
Mercedes-Benz Description: Filler connection. High-pressure line. Cover, service connection, high pressure, air conditioning system. Filling connection m10x1. High-pressure side M10X1. To refrigerant line. Valve.
MSRP $6.75
$5.52
MSRP $6.75
$5.52
90
MSRP $1.70
$1.38
115
Temperature Sensor Mercedes-Benz
Mercedes-Benz Description: Temperature sensor, heat exchanger, high-voltage battery. Evaporator .
MSRP $119.00
$93.72
MSRP $119.00
$93.72
120
MSRP $226.00
$171.45
125
O-Ring Mercedes-Benz
Mercedes-Benz Description: Intake side. Upper. Expansion valve connection. Line to check valve. Piping to refrigerant compressor. Refrigerant line to connecting point and compressor 3/4". Evaporator. Refrigerant line to expansion valve .
MSRP $5.50
$4.42
MSRP $5.50
$4.42
140
Elastomer Bearing Mercedes-Benz
Mercedes-Benz Description: Bearing. Evaporator to holder . Holder to strut.
MSRP $5.50
$4.55
MSRP $5.50
$4.55
145
Inner Sleeve For Bearing Mercedes-Benz
Mercedes-Benz Description: Elastomer bearing inner sleeve. Evaporator to holder .
150
MSRP $210.00
$158.75
165
Valve Element Mercedes-Benz
Mercedes-Benz Description: Filling connection. Filler connection. High-pressure line. Filling valve. Suction line. Service connection, high pressure, air conditioning system. Valve element. To refrigerant line.
MSRP $19.50
$15.87
MSRP $19.50
$15.87
170
Power Steering Pump Bolt Mercedes-Benz
Mercedes-Benz Description: M8x30. Bracket to transmission cover. Bracket to transmission m 8x30. Slave cylinder to transmission case. Front exhaust pipe to transmission m8 x 30. Bracket to mounting plate or to transmission.
MSRP $4.00
$3.31
MSRP $4.00
$3.31
180
Screw Cap Mercedes-Benz
Mercedes-Benz Description: Filler connection. Filling connection. Low-pressure line. Seal. Suction line. Cover, service connection, low pressure, air conditioning system. Low-pressure side M8X1. To refrigerant line. Valve.
MSRP $12.00
$9.94
MSRP $12.00
$9.94
245
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: M8x25-8.8. Fuel tank to console. Bracket to mounting plate or to transmission. Bracket to bumper. Shackle to torsion bar. Intermediate bearing to frame.
MSRP $4.20
$3.45
MSRP $4.20
$3.45
260
MSRP $112.00
$88.44
315
Spacer Mercedes-Benz
Mercedes-Benz Description: Refrigerant line. Between the lines. Purge line to engine. Vacuum line to fuel line.
400
MSRP $316.00
$240.03
460
480
485
MSRP $39.50
$32.43
550
550
Hexagon Head Screw Mercedes-Benz
Mercedes-Benz Description: Pressure line to rear evaporator. M6x34. Refrigerant line to condenser. Hose line mount.
