Brake Lines for 2002 Mercedes-Benz CLK430
No.
Part # / Description / Price
Price
5
Line
Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: From main cylinder to hydraulic unit connection "sc". From master cylinder,connection "v",to hydraulic unit,connection: "v".
8
Line Mercedes-Benz
Mercedes-Benz Description: (return line) from coupling piece to oil reservoir. From high pressure expansion hose to coupling piece. From high pressure expansion hose to control valve. From pump to service valve. (return line) from distributor to distributor. From master cylinder,connection "h",to hydraulic unit,connection: "h",teves. High-pressure line to connection fitting. From distributor to oil tank.
MSRP $63.00
$49.88
MSRP $63.00
$49.88
8
Line Mercedes-Benz
Mercedes-Benz Description: From master cylinder,connection "h",to hydraulic unit,connection: "h",bosch.
11
Line Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: From master cylinder to rear hydraulic unit. From adapter fitting to hydraulic unit,connection: "e". From front master cylinder to hydraulic unit,connection: "h". From hydraulic unit to adapter fitting,front right teves-ate. Red 830 mm. From master cylinder,connection "v",to hydraulic unit,connection: "v". From distributor to pressure switch. From hydraulic unit to right front wheel. From hydraulic unit to left front wheel teves. From hydraulic unit to adapter fitting,rear right.
MSRP $61.00
$48.55
MSRP $61.00
$48.55
11
Line Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: From distributor to rear right brake hose. From rear master cylinder to hydraulic unit,connection: "v". From hydraulic unit,connection "p",to accumulator,connection: "p". From master cylinder to front hydraulic unit. From master cylinder,connection "v",to hydraulic unit,connection: "v". Red 865 mm. From right rear hydropneumatic spring leg to distributor. From height control valve in engine compartment to left distributor.
MSRP $55.00
$43.89
MSRP $55.00
$43.89
14
Line Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: From booster brake to distributor at brake master cylinder. Vom ueberg.st.2 zum vorderrad links. From master cylinder to rear hydraulic unit. From hydraulic unit to adapter fitting,front right bosch. Red 735 mm. From hydropneumatic spring leg to distributor. Adapter fitting to left front wheel.
17
Line Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: From master cylinder to front right brake hose. 4.75 x 0.7 x 1290 mm. From adapter fitting to right front wheel. 4.75 x 0.7 x 1290 mm. From adapter fitting to brake hose, rear right. 4.75 x 0.7 x 1290 mm. From brake master cylinder to right front wheel. 4.75 x 0.7 x 1290 mm. From hydraulic unit to adapter fitting,rear left. 4.75 x 0.7 x 1290 mm. From hydraulic unit to adapter fitting,rear right. 4.75 x 0.7 x 1290 mm.
MSRP $73.00
$57.86
MSRP $73.00
$57.86
21
Line Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: From rear master cylinder to coupler. 4.75 x 0.7 x 1395 mm. From hydraulic unit to adapter fitting,rear left. 4.75 x 0.7 x 1395 mm. From brake master cylinder to right bracket. 4.75 x 0.7 x 1395 mm. From hydraulic unit,connection "p",to accumulator,connection: "p". 4.75 x 0.7 x 1395 mm. From hydraulic unit to adapter fitting,rear right. 4.75 x 0.7 x 1395 mm.
MSRP $72.00
$57.19
MSRP $72.00
$57.19
23
Line Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: From adapter fitting to brake hose, rear left. 4.75x0.7x2890 mm.
29
Line Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: From front master cylinder to distributor. 4.75x0.7x3660 mm. From adapter fitting to brake hose, rear right. 4.75x0.7x3660 mm.
32
Hexagon Spacer Element Mercedes-Benz
Mercedes-Benz Description: Connection. M10. Between hydraulic unit lines and left/right rear axle lines. Brake line. Coupling piece to left rear wheel. Vom ueberg.st.2 zum vorderrad links. Adapter. Between the lines.
MSRP $7.25
$5.93
MSRP $7.25
$5.93
44
MSRP $12.00
$9.94
50
MSRP $37.00
$30.36
53
Retaining Spring Mercedes-Benz
Mercedes-Benz Description: Brake hose mounting. Between master cylinder,front axle and bracket,frame. Rear axle. Front left. Brake hose to bracket. Line connections. Bracket, brake line/brake hose. Brake line to brake hose.
MSRP $1.70
$1.38
MSRP $1.70
$1.38
56
MSRP $7.25
$5.93
60
Retaining Screw Mercedes-Benz
Mercedes-Benz Description: M12x1. Line connection. Brake line. Hydraulic line. Lines m 12x1. Dia., 6,3 . M 12. 620mm. From brake master cylinder to hydraulic unit.
MSRP $0.90
$0.69
MSRP $0.90
$0.69
68
Rubber Guide Mercedes-Benz
Mercedes-Benz Description: Brake line to left front wheelhouse panel. Brake line to battery frame,top. Brake line to fire wall. Spacing of brake lines. Brake line to front axle cross member. Left front brake line to connection support. At side member,bottom right.
MSRP $5.25
$4.28
MSRP $5.25
$4.28
71
Clamp Mercedes-Benz
Mercedes-Benz Description: Condensed water drain. Compressor-to-condenser refrigerant line to condenser. Starting cable to side member.
80
Holder Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: Brake line to transverse control arm, front left. Right front brake line to tunnel, bottom.
MSRP $2.90
$2.35
MSRP $2.90
$2.35
83
Rubber Guide Mercedes-Benz
Mercedes-Benz Description: Spacing of lines,rear. Spacing of brake lines. Brake line to left front wheelhouse panel. Brake line to cross member. Spacing of line above wheel arch. Bunching and distancing brake line. On fire wall.
104
Holder Mercedes-Benz
Mercedes-Benz Description: Hose to suction line. Vacuum line to fire wall. Line mounting. Oxygen sensor.
