Electrical Parts Used for Transmission for 2006 Mercedes-Benz E320
No.
Part # / Description / Price
Price
350
Electric Line
Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: 5-speed automatic transmission with keyless go.
350
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: 5-speed automatic transmission.
350
Electric Line Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: 5-speed automatic transmission with keyless go.
350
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: UP TO IDENT. NUMBER A303555, ORDER OBJECT NUMBER WITHOUT ES1
AS OF IDENT. NUMBER A303556, ORDER OBJECT NUMBER WITH ES1 98
AS OF IDENT. NUMBER A303556, ORDER OBJECT NUMBER WITH ES1 98
Description: 5-speed automatic transmission with keyless go.
350
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: 5-speed automatic transmission.
350
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: UP TO IDENT. NUMBER A303555, ORDER OBJECT NUMBER WITHOUT ES1
AS OF IDENT. NUMBER A303556, ORDER OBJECT NUMBER WITH ES1 98
AS OF IDENT. NUMBER A303556, ORDER OBJECT NUMBER WITH ES1 98
Description: 5-speed automatic transmission with keyless go.
350
350
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: 5-speed automatic transmission with keyless go.
350
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: UP TO IDENT. NUMBER A303555, ORDER OBJECT NUMBER WITHOUT ES1
AS OF IDENT. NUMBER A303556, ORDER OBJECT NUMBER WITH ES1 98
AS OF IDENT. NUMBER A303556, ORDER OBJECT NUMBER WITH ES1 98
Description: 5-speed automatic transmission.
350
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: UP TO IDENT. NUMBER A303555, ORDER OBJECT NUMBER WITHOUT ES1
AS OF IDENT. NUMBER A303556, ORDER OBJECT NUMBER WITH ES1 98
AS OF IDENT. NUMBER A303556, ORDER OBJECT NUMBER WITH ES1 98
Description: 5-speed automatic transmission.
360
Plug Mercedes-Benz
Mercedes-Benz Description: Left front door connector, green x35/1. 2-pin slk2.8model 1: slkmodel 2: 2.8slots: 2. Emergency speaker connector right front x18/36. 2-pin slk2.8model 1: slkmodel 2: 2.8slots: 2. Radio remote control separation point for central locking x35/71. 2-pin slk2 ...
MSRP $5.50
$4.55
MSRP $5.50
$4.55
380
Plug Mercedes-Benz
Mercedes-Benz Description: Transmission diagnosis connection x11/32. 2-pin mqs. Radio "mute" plug connection x39/12. 2-pin mqs. Two-way radio speaker separation point x1/45. 2-pin mqs. Connector rear floor frame floor system x8/18. 2-pin mqs. Separation point microphone hands-free system x58/3. 2-pin mqs. M2/2. 2-pin mqs. Separation point aux. Turn sign. Ind. X52/5. 2-pin mqs.
MSRP $2.70
$2.21
MSRP $2.70
$2.21
500
Distributor Mercedes-Benz
Mercedes-Benz Description: Can bus distributor x30/5. 12x2/1x3 pin. Potential distributor can c x63/4. 12x2/1x3 pin. Can bus c, right x30/19. 12x2/1x3 pin. Can c connector x63/4. 12x2/1x3 pin. Connector can databus x63/4,. 12x2/1x3 pin. Can bus c, left x30/5. 12x2/1x3 pin. Can bus c x30/18. 12x2/1x3 pin. Can bus c, left x63/4. 12x2/1x3 pin. Voltage distributor, can bus 27-pin. 12x2/1x3 pin.
MSRP $37.00
$30.36
MSRP $37.00
$30.36
800
Plug Mercedes-Benz
Mercedes-Benz Description: Cockpit/electric steering lock connector x190. 4-pin slk2.8model 1: slkmodel 2: 2.8slots: 4release tool: w220 589 01 99 62. Left rear door connector to frame floor system (x35/3). 4-pin slk2.8model 1: slkmodel 2: 2.8slots: 4release tool: w220 589 01 99 62. ...
MSRP $4.20
$3.45
MSRP $4.20
$3.45
850
Plug Mercedes-Benz
Mercedes-Benz Description: Module box separation point x35/15. 3-pin. Radio remote control separation point for central locking x35/71. 3-pin. Separation point trunk lid 14-pin x8/4. 3-pin. Control unit box/engine sep. Point x35/63. 3-pin.
MSRP $4.40
$3.59
MSRP $4.40
$3.59
860
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: Rear rpm sensor connector x62/1. MQS. 0.5 MM2 MQS SN
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
MSRP $9.50
$7.87
MSRP $9.50
$7.87
