Independent Heating for 2006 Mercedes-Benz E320
No.
Part # / Description / Price
Price
50
55
Clamp
Mercedes-Benz
Mercedes-Benz Description: From heater unit to muffler. 24-26/ 16 mm. As required. 24-26/ 16 mm. Exhaust pipe to muffler. 24-26/ 16 mm.
75
Hose Clamp Mercedes-Benz
Mercedes-Benz Description: HOSE AT LINEDiameter: 8mmInside diameter: 8,5mmOutside diameter: 9,5mmMaterial thickness: 0,6mm. Sep. POINT D-PILLAR TO REAR PANELDiameter: 8mmInside diameter: 8,5mmOutside diameter: 9,5mmMaterial thickness: 0,6mm. FUEL LINE TO HEATER UNITDiameter: 8mmInsi ...
MSRP $6.00
$4.97
MSRP $6.00
$4.97
95
Spring Hose Clamp Mercedes-Benz
Mercedes-Benz Description: 28-31 mm. 26-29.2 mm. 27 mm. 26-29.2 mm.
MSRP $7.25
$5.93
MSRP $7.25
$5.93
135
Clamp Mercedes-Benz
Mercedes-Benz Description: Heat duct to front longitudinal memb. Right 3,2mm. Brake line mounting to main floor right 3,2/4,7-6mm. Front right brake line mounting to right longitudinal member 3,2/4,7-6mm.
140
MSRP $2.50
$2.07
140
Hexalobular Screw Mercedes-Benz
Mercedes-Benz Description: Rear lid to hinge lever. Drive to rear pillar. Pipe line to shock absorber leg reinforcement. Strut to front cross member. Bracket to car floor. Cooling pipe to front cross member. Engine hood upper catch to engine hood. Partition panel. Strut to stiffening,front central.
160
Rubber Bushing Mercedes-Benz
Mercedes-Benz Description: Fuel-oil pump. Fuel pump on cross member. On suction side.
165
Rubber Bushing Mercedes-Benz
Mercedes-Benz Description: Fuel-oil pump. Fuel pump on cross member. On delivery side.
170
180
Clamp Mercedes-Benz
Mercedes-Benz Description: Breather line to activated charcoal filter. 10x6 mminside diameter: 10mmmaterial thickness: 0,6mm. BETWEEN FUEL LINE AND HEATER UNIT. 10X6 MMInside diameter: 10mmMaterial thickness: 0,6mm. HOSE TO FUEL PUMP. 10X6 MMInside diameter: 10mmMaterial thickness: ...
MSRP $4.50
$3.73
MSRP $4.50
$3.73
200
Hose Clamp Mercedes-Benz
Mercedes-Benz Description: FUEL TANK TO HOSE. 9 MM - 9.5 MMInside diameter: 9,5mmOutside diameter: 11mmMaterial thickness: 0,6mm. BREATHER LINE TO ACTIVATED CHARCOAL FILTER. 9 MM - 9.5 MMInside diameter: 9,5mmOutside diameter: 11mmMaterial thickness: 0,6mm. FUEL PUMP TO TANK. 9 MM - ...
MSRP $2.50
$2.07
MSRP $2.50
$2.07
205
210
210
210
Remote Control Receiver Mercedes-Benz
Mercedes-Benz Description: Stationary heater. Independent heating. Auxiliary heater. Auxiliary heating. Remote control.
220
Hose Mercedes-Benz
Mercedes-Benz Description: Heat duct to front longitudinal memb. Chafe protection
Inside diameter: 3mm
Outside diameter: 8mm. FUEL LINE
Inside diameter: 3mm
Outside diameter: 8mm.
Inside diameter: 3mm
Outside diameter: 8mm. FUEL LINE
Inside diameter: 3mm
Outside diameter: 8mm.
225
Battery Mercedes-Benz
Mercedes-Benz Description: Replacement battery, remote control
Diameter: 13mm
Model 2: IEC 60086
Volt: 3V
Amps: 160mAH
Gefahrgutkennzeichen: 1.9 Miscellaneous dangerous goods (small lithium batteries). TRANSMITTER CR 11108
Diameter: 13mm
Model 2: IEC 60086
Volt: 3V
Amps: 160mAH
Gefahrgutkennzeichen: 1.9 Miscellaneous dangerous goods (small lithium batteries).
Diameter: 13mm
Model 2: IEC 60086
Volt: 3V
Amps: 160mAH
Gefahrgutkennzeichen: 1.9 Miscellaneous dangerous goods (small lithium batteries). TRANSMITTER CR 11108
Diameter: 13mm
Model 2: IEC 60086
Volt: 3V
Amps: 160mAH
Gefahrgutkennzeichen: 1.9 Miscellaneous dangerous goods (small lithium batteries).
225
Battery Mercedes-Benz
Mercedes-Benz Description: IEC 86-MN 21
Diameter: 10mm
Model 2: IEC 60086
Volt: 12V
Amps: 33mAH. For transmitter.
Diameter: 10mm
Model 2: IEC 60086
Volt: 12V
Amps: 33mAH. For transmitter.
250
Hexalobular Screw Mercedes-Benz
Mercedes-Benz Description: Bracket to covering. Filler neck recess m 6x16. Bracket mounting m6x20. Headlamp wiper/washer.
MSRP $3.70
$3.04
MSRP $3.70
$3.04
310
Hexagon Nut With Collar Mercedes-Benz
Mercedes-Benz Description: Oxygen sensor. 5 mm. Bracket mounting. 5 mm. Control module,auxiliary fan. 5 mm.
MSRP $4.00
$3.31
MSRP $4.00
$3.31
800
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Heater booster control module n33/2. 2-pin jpt. Additional heater control unit. 2-pin jpt. Control unit independent heating. 2-pin jpt. Stationary heater plug connector n33/2. 2-pin jpt. Additional heater equipment in engine compartment n33. 2-pin jpt.
850
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: WITH GASKET. 0.5-1.00 MM2 JPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Model 1: JPTModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. Silver-plated, with single-wire seal. 0.5-1.00 MM2 JPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Model 1: ...
MSRP $8.00
$6.49
MSRP $8.00
$6.49
860
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
MSRP $8.00
$6.49
MSRP $8.00
$6.49
