Wiring Harness Telecommunications/Audio Compact Set for 2007 Mercedes-Benz CLS550
No.
Part # / Description / Price
Price
10
10
Wiring Harness
Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Telecommunications with radio (audio).
10
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Telecommunications with radio (audio). Navigation preinstallation.
300
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Telecommunications with radio (audio).
300
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Telecommunications with radio (audio).
300
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Telecommunications with radio (audio).
300
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Telecommunications with radio (audio).
300
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Telecommunications with radio (audio).
300
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Telecommunications with radio (audio).
500
Housing Mercedes-Benz
Mercedes-Benz Description: Transceiver connector, blue x39/5. 10-pin mqs. Telephone-portable ctel separation point, blue x39/37*3. 10-pin mqs. Breakdown/information button conn. X39/48. 10-pin mqs. Blue center console connector x29/6. 10-pin mqs. Plug connection handy x39/39. 10-pin mqs. Mobile phone disconnecting point. 10-pin mqs. Connector, telephone, armrest, blue x39/47. 10-pin mqs.
510
Crimp Tml Pin Contact Mercedes-Benz
Mercedes-Benz Description: X1/16. 0.5-0.75 MM2 MQSLeitungsquerschnitt Min/Max: 0,5-0,75mm2Oberflächenschutz PINs: SnELA: -Model 1: MQSRelease tool: W220 589 01 99 60Crimp tool: W220 589 01 99 85. Malfunction indicator lamp aut. Breakdown/information button conn. X 39/48. 0.5-0.75 M ...
MSRP $2.80
$2.28
MSRP $2.80
$2.28
520
Plug Mercedes-Benz
Mercedes-Benz Description: To 168 545 09 40. Breakdown/information button conn.
MSRP $7.00
$5.66
MSRP $7.00
$5.66
520
Plug Housing Mercedes-Benz
Mercedes-Benz Description: Connector for transceiver part x39/5. 10-pin. Connector cockpit/frame floor system x18/35. 10-pin. Air conditioner cable harness plugconnection. 10-pin. Transceiver connector, black x39/5. 10-pin. Breakdown/information button conn. X39/48. 10-pin. Tail lamp cable harness plugconnection. 10-pin.
530
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
MSRP $7.00
$5.80
MSRP $7.00
$5.80
540
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Contact strip front pass. Side yel. Automatic child seat recognition. 4-pin mqs
model 1: mqs
slots: 4. Seat contacting. 4-pin mqs
model 1: mqs
slots: 4. Separation point, upfront sensor, driver x18/38. 4-pin mqs
model 1: mqs
slots: 4.
model 1: mqs
slots: 4. Seat contacting. 4-pin mqs
model 1: mqs
slots: 4. Separation point, upfront sensor, driver x18/38. 4-pin mqs
model 1: mqs
slots: 4.
MSRP $4.50
$3.73
MSRP $4.50
$3.73
800
Line Connector Mercedes-Benz
Mercedes-Benz Description: Connector distributor wake-up/ diagnostics 10-pin x30/14. 10-pin slk2.8. Distributor, terminal 58d x30/13. 10-pin slk2.8. Connector distributor wake-up/ diagnostics 10-pin x 30/14. 10-pin slk2.8. Potential distributor kl.31 z204/5. 10-pin slk2.8. Plug distributor wake-up signal 10 pin x30/8,. 10-pin slk2.8. Below left rear seat z204/6. 10-pin slk2.8. Distributor, terminal 15 x30/9,code a. 10-pin slk2.8.
MSRP $7.00
$5.80
MSRP $7.00
$5.80
