Trunk Lid for 2007 Mercedes-Benz CLS550
No.
Part # / Description / Price
Price
25
Plug-In Fastener
Mercedes-Benz
Mercedes-Benz Description: Lining to backrest frame
Diameter: 7,8mm. Cable duct on hinge lever
diameter: 7,8mm. Fastening, sidewall
diameter: 7,8mm. Left covering
diameter: 7,8mm. Right trunk lining
Diameter: 7,8mm. Bottom trunk sill
diameter: 7,8mm. Mount, right trim
Diameter: 7,8mm. Protective padding mount
Diameter: 7,8mm.
Diameter: 7,8mm. Cable duct on hinge lever
diameter: 7,8mm. Fastening, sidewall
diameter: 7,8mm. Left covering
diameter: 7,8mm. Right trunk lining
Diameter: 7,8mm. Bottom trunk sill
diameter: 7,8mm. Mount, right trim
Diameter: 7,8mm. Protective padding mount
Diameter: 7,8mm.
MSRP $2.40
$1.93
MSRP $2.40
$1.93
30
MSRP $155.00
$122.76
40
MSRP $99.00
$77.88
40
MSRP $74.00
$58.52
50
Screw Mercedes-Benz
Mercedes-Benz Description: M6x11. Left and right flap paneling to hinge. Hood to hinge. Fastening, strikers. Outside flap to left hinge. Hinge to trunk lid.
MSRP $1.20
$0.97
MSRP $1.20
$0.97
60
MSRP $20.00
$16.56
70
Screw Mercedes-Benz
Mercedes-Benz Description: M8x55. For hinge to shell. Hinge mounting. Hinge at body shell, left. Hinge to body-in-white.
80
Nut Mercedes-Benz
Mercedes-Benz Description: Spring strut to body. M8
Diameter: 8mm
Strength / hardness class: 8
Thread code letter: M
Thread pitch: 1,25mm
Outside diameter: 17,9mm
Width across flats: 13mm. Suspension strut to body. Torsion bar on body.
Diameter: 8mm
Strength / hardness class: 8
Thread code letter: M
Thread pitch: 1,25mm
Outside diameter: 17,9mm
Width across flats: 13mm. Suspension strut to body. Torsion bar on body.
110
Electric Motor Mercedes-Benz
Mercedes-Benz Notes: Part A 219 820 03 42 26 is delivered without control unit Part A 219 820 05 26
Description: Remote trunk release.
MSRP $1,020.00
$756.40
MSRP $1,020.00
$756.40
115
Control Unit Mercedes-Benz
Mercedes-Benz Notes: PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
NO LONGER AVAILABLE
NO LONGER AVAILABLE
Description: Remote trunk release.
120
Electrical System Mercedes-Benz
Mercedes-Benz Notes: PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
Description: Electric motor. Remote trunk closing. Remote trunk locking.
150
MSRP $77.00
$61.18
170
Switch Mercedes-Benz
Mercedes-Benz Description: Remote trunk release. Remote trunk locking. Trunk lid remote control. Remote trunk closing.
MSRP $72.00
$57.19
MSRP $72.00
$57.19
170
Switch Mercedes-Benz
Mercedes-Benz Description: Remote trunk locking and keyless go. Remote trunk release. Trunk lid remote control. Push button, remote trunk lid/liftgate closing. Remote trunk locking with keyless go. Remote trunk closing with KEYLESS-GO. Remote trunk closing and KEYLESS-GO.
MSRP $81.00
$64.51
MSRP $81.00
$64.51
180
Rubber Bumper Mercedes-Benz
Mercedes-Benz Description: At trunk lid, bottom. Rear lid stiffening. For gap dimension. On rear lid. Tank attachment. To trunk lid below, side. Rear lid stop to rear body panel, bottom 14 mm. To lower trunk lid. At engine hood.
MSRP $4.20
$3.41
MSRP $4.20
$3.41
200
Stop Plug Mercedes-Benz
Mercedes-Benz Description: IN COVERING A-PILLAR RIGHT. 6.5mm
Inside diameter: 6,5mm
Outside diameter: 9mm. To trunk lid. 6.5mm
Inside diameter: 6,5mm
Outside diameter: 9mm. PAINT RUN-OFF HOLES IN REAR PANEL. 6.5mm
Inside diameter: 6,5mm
Outside diameter: 9mm. FOR PLUGGING THE BORES IN THE WHEEL HOUSE. 6.5mm
Inside diameter: 6,5mm
Outside diameter: 9mm. PAINT HOLE IN TRUNK LID 6.5mm. 6.5mm
Inside diameter: 6,5mm
Outside diameter: 9mm.
Inside diameter: 6,5mm
Outside diameter: 9mm. To trunk lid. 6.5mm
Inside diameter: 6,5mm
Outside diameter: 9mm. PAINT RUN-OFF HOLES IN REAR PANEL. 6.5mm
Inside diameter: 6,5mm
Outside diameter: 9mm. FOR PLUGGING THE BORES IN THE WHEEL HOUSE. 6.5mm
Inside diameter: 6,5mm
Outside diameter: 9mm. PAINT HOLE IN TRUNK LID 6.5mm. 6.5mm
Inside diameter: 6,5mm
Outside diameter: 9mm.
MSRP $4.90
$4.00
MSRP $4.90
$4.00
220
Damping Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Padding for lining in center behind battery compartment. Below rear carpet left and right. On rear lid - tension spring.
290
Felt Strip Mercedes-Benz
Mercedes-Benz Description: Adhesive strip. 100X70X3MM. Damping. 100X70X3MM. Loading floor,left. 100x70x3mm. Via screws to steering, left and right. 100X70X3MM. Left support. 100X70X3MM. On folding top case cover. 100x70x3mm. Rear seat bottom. 100x70x3mm. Below rear seat at left on cardan shaft tunnel. 100x70x3mm.
MSRP $3.90
$3.17
MSRP $3.90
$3.17
300
MSRP $1.50
$1.24
310
MSRP $238.00
$180.34
330
Spreader Nut Mercedes-Benz
Mercedes-Benz Description: HANDLE TO REAR LID
Diameter: 8mm
Strength / hardness class: PA66
Thread code letter: K50
Outside diameter: 18mm
Width across flats: 18mm. MOULDING TYPE HANDLE TO REAR PANEL DOOR
Diameter: 8mm
Strength / hardness class: PA66
Thread code letter: K50
Outside diameter: 18mm
Width across flats: 18mm.
Diameter: 8mm
Strength / hardness class: PA66
Thread code letter: K50
Outside diameter: 18mm
Width across flats: 18mm. MOULDING TYPE HANDLE TO REAR PANEL DOOR
Diameter: 8mm
Strength / hardness class: PA66
Thread code letter: K50
Outside diameter: 18mm
Width across flats: 18mm.
MSRP $2.50
$2.07
MSRP $2.50
$2.07
330
Blind Clinch Nut Mercedes-Benz
Mercedes-Benz Description: License-plate mounting. Housing to rear lid. Handle ledge to rear lid.
340
Pan Head Screw Mercedes-Benz
Mercedes-Benz Description: Left roof mechanism mount. Fastening, roof mechanism 5x16. Handle to rear lid.
MSRP $6.75
$5.56
MSRP $6.75
$5.56
340
Countersunk Screw Mercedes-Benz
Mercedes-Benz Description: Handle strip to rear-end door. Moulding type handle to rear panel door. Mounting, handle. Handle to rear lid.
MSRP $2.90
$2.35
MSRP $2.90
$2.35
710
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: WITH GASKET. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. Silver-plated, with single-wire seal. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. X22/2. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62.
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. Silver-plated, with single-wire seal. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62. X22/2. 2.5 MM2 SLK2.8
Leitungsquerschnitt Min/Max: 2,5mm2
Model 1: SLK
Model 2: 2.8
Release tool: W220 589 01 99 62.
MSRP $11.50
$9.37
MSRP $11.50
$9.37
720
Plug Mercedes-Benz
Mercedes-Benz Description: Driver door airbag sys. Sensor b48/7. 3-pin mqs. Left rear door pressure sensor B48/9. 3-PIN MQS.
MSRP $2.70
$2.21
MSRP $2.70
$2.21
